Aeroflow 3/4" Barb Brushless Electric Supercharger & Water Pump AF49-1051

Roll over image to zoom in Click on image to zoom

Aeroflow 3/4" Barb Brushless Electric Supercharger & Water Pump AF49-1051

AF49-1051 - LSA REMOTE ELECTRIC WATER

Save 10%

Aeroflow PerformanceSKU: AF49-1051

Product: 19mm Inlet/Outlet Barb, 40 Litres Per Minute

Variant

Price:

$437.45 NZD $483.63 NZD

Tax included Shipping calculated at checkout

Quantity:

Instructions

Thanks for shopping at Stealth Ride. Please note - We try to keep on top of all Stock levels - If your order is urgent please let us know in the notes section of your order. Occasionally items are backordered with our suppliers - This can cause an extra 2-3 days added to your shipment. We will cancel your order if we cannot supply within your given time frame

3/4" Barb Brushless Electric Supercharger & Water Pump19mm Inlet/Outlet Barb, 40 Litres Per Minute
Brand: AEROFLOW
Part Number: AF49-1051
Description:

The Aeroflow Performance brushless electric water pump is designed for universal fitment to compliment or replace a vehicle’s existing mechanical belt-driven water pump. This brushless design is a magnetically driven water pumpwhich allows high flow of up to 46.6 Litres Per Minute withthe larger 1 inch (25.4mm) barb and 40 Litre Per Minute on the smaller 3/4 Inch (19.05mm) barb. Being a brushless design it has no brushes to ever wear out and the pump is magnetically driven by the motor, which means that no shaft sealing isrequired.

WARNING : Do NotRun This Water Pump Dry. Warranty will be VOID if the pump is run without fluid.

Additional Specifications:

Pump Dimensions:
Overall Height: 96mm
Pump Diameter: 60mm
Overall Length: 123mm
Mounting Bolt Centre: 77mm

Voltage: DC 12 Volts
Voltage Range: DC 10 Volt to 16 Volt
Withstanding Voltage: 20 Volts
Current: 5.6 Amps
Max Power: 67.2W

Flow Rate: 2500 LPH
Pressure: 8 M

Inlet Barb Diameter: 22mm (55/64")
Outlet Barb Diameter: 22mm (55/64")

Water Temperature: -10°C to 105°C (-10 to 221°F)
Ambient Temperature: -10°C to 85°C (-10 to 185°F)
Storage Temperature: -10°C to 85°C (-10 to 185°F)

Pump Body Material: PA66 + 30% GF / Aluminium
Noise Level : Less Then 40 Decibel
Controller: Built in
Weight: 800 Grams
