BOOSTED 6766 T4 Turbocharger Specifications
Recommended horsepowerrating: 550-950HP
Recommended engine displacement: 2.0L to 6.0L
- 360° journal bearing
- Point Milled 7075 billet 6 + 6 compressor wheel
- This is an oil cooled turbocharger
- External wastegate sold separately
- Inlet flange gasket and turbo drain gasket included inturbo kit
- Must use a -6AN oil feel line to maintaincore temperature (Warranty VOID if not used)
- 1/8" NPT oil feedfitting (sold separately) or a38mm 2-bolt oil feed plate with M8 x 1.25mm thread size
- 50.80mm bolt centre turbo drain flange withM8 x 1.25mm thread size
Compressor Specifications
Inducer: 67.40mm
Exducer: 82mm
Extended Tip: 88.30mm
Turbine Specifications
Inducer: 74mm
Exducer: 66.10mm
Wastegate
External wastegate
Important Information:
Boosted by Aeroflow products are manufactured to industry standard specifications from quality materials. Utmost care is taken to ensure products are free from blemishes, inconsistencies and defects. Aeroflow products carry a one year warranty from the date ofpurchase however warranty willbe void if the product is not used in the correct way for which it was intended. BoostedTurbochargers and replacement parts are designed for street use only. Products used in race applications and/or products that have been modified, damaged, incorrectlyinstalled or incorrectly/poorly maintained are not covered by this warranty. Proof of purchase will be required for all warranty claims.
Boosted360° journal bearing turbochargers must use a -6AN oil feel line to maintain coretemperature.
