Aeroflow Gloss Blue 90° Silicone Reducer / Expander Hose 1" (25mm) to 5/8" (16mm) I.D AF9

Roll over image to zoom in Click on image to zoom

Aeroflow Gloss Blue 90° Silicone Reducer / Expander Hose 1" (25mm) to 5/8" (16mm) I.D AF9

AF9003-100-070 - Silicone Hose Reducer 90 Deg;

Aeroflow PerformanceSKU: AF9003-100-070

Product: 5mm Wall Thickness, 127mm Leg

Variant

Price:

$10.65 NZD

Tax included Shipping calculated at checkout

Quantity:

Thanks for shopping at Stealth Ride. Please note - We try to keep on top of all Stock levels - If your order is urgent please let us know in the notes section of your order. Occasionally items are backordered with our suppliers - This can cause an extra 2-3 days added to your shipment. We will cancel your order if we cannot supply within your given time frame

Gloss Blue 90° Silicone Reducer / Expander Hose 1" (25mm) to 5/8" (16mm) I.D5mm Wall Thickness, 127mm Leg
Brand: AEROFLOW
Part Number: AF9003-100-070
Description:

Aeroflow designs and manufactures premium quality silicone hose for the Performance Automotive Industry, Transport Industry and Industrial applications. Whether it's silicone heater hose, vacuum or high temperature silicone turbo hose, Aeroflow has the right products for your demanding applications.

- 5mm wall thickness
- 127mm (5") Length
- Working temperature -60 to +180° C (-75 to +350° F)
- Excellent ply adhesion from the inner core to the outer layers
- Bright gloss Blue finish
- Not recommended for use with oil and fuel
- Weather resistance to harsh sunlight, dry conditions and rain water

Note: Leg sizes are approximate and may vary.

Additional Specifications:

Larger Internal Diameter: 25.4mm
Larger Outside Diameter: 34.4mm
Smaller Internal Diameter: 16mm
Smaller Outside Diameter: 27mm
Leg Length: 150mm

Recommended Hose Clamp (Guide Only):
Worm Drive Clamp: AF23-2144 (large side) and AF23-1832 (small side)
Constant Tension Clamp: AF28-2639/AF28-2639BLK
