Aeroflow Bare Small Block Chev 327-350-400 186cc Aluminium Cylinder Heads with 67cc Chamb

Roll over image to zoom in Click on image to zoom

Aeroflow Bare Small Block Chev 327-350-400 186cc Aluminium Cylinder Heads with 67cc Chamb

AF95-0327 - SBC 180cc ALUMINIUM HEADS BARE

Aeroflow PerformanceSKU: AF95-0327

Product: 2.00" x 1.20" Intake Port, 1.42" x 1.53" Exhaust Port

Variant

Price:

$1,276.37 NZD

Tax included Shipping calculated at checkout

Quantity:

Instructions

Thanks for shopping at Stealth Ride. Please note - We try to keep on top of all Stock levels - If your order is urgent please let us know in the notes section of your order. Occasionally items are backordered with our suppliers - This can cause an extra 2-3 days added to your shipment. We will cancel your order if we cannot supply within your given time frame

Bare Small Block Chev 327-350-400 186cc Aluminium Cylinder Heads with 67cc Chamber (Pair)2.00" x 1.20" Intake Port, 1.42" x 1.53" Exhaust Port
Brand: AEROFLOW
Part Number: AF95-0327
Description:

The Aeroflow Series of Aluminium Cylinder Heads are taking affordable performance street and strip cylinder heads to the next level. Theseheads utilise ultra-smooth A356-T6 aluminium castings, new as-cast runner and chamberdesigns produce excellent flownumbers. This combined with a 5-angle competition valve job,diamond-honed bronze guides, hand bowl blending and professional assembly help to outperform some of the best brands in the business.

The Aeroflow Performance small block Chevy cylinder heads are designed for entry level street performance engines to give the ultimate in flow at a budget price. Made from A356 aluminium castings, the 186cc cylinder heads are ideal for operating in the idle to 6500 rpm range. These cylinder heads will fit a 4.00" bore and larger.

Additional Specifications:

Head Specifications

Material: A356 Aluminium
Chamber Chamber: 67cc
Intake Port Volume: 186cc
Intake Port Dimension: 2.00" x 1.20"
Exhaust Port Volume: 72cc
Exhaust Port Dimension: 1.42" H x 1.53" W
Spark Plug Location: Straight
Intake Valve Diameter: 2.02"
Exhaust Valve Diameter: 1.60"
Valve Stem Diameter: 11/32"
Valve Spring Pocket I.D.: 1.49"
Valve Guide Material: Manganese Bronze
Valve Guide O.D.: .530" (.570" at base)
Rocker Stud Thread Size: 7/16" x 14
Valve Angle: 23°
Deck Thickness: .625"

Important Information:

IMPORTANT NOTICE:

We recommend to check installed spring seat pressure & open pressure before installing your cylinder headsto make sure the spring pressure is correct for your application.
