2.60" x 1.28" Intake Port, 1.47" x 1.64" Exhaust Port
Material: A356 Aluminium
Chamber Chamber: 70cc
Intake Port Volume: 276cc
Intake Port Dimension: 1.30" x 2.61"
Exhaust Port Volume: 92cc
Exhaust Port Dimension: 1.475" H x 1.65" W
Spark Plug Location: OE Stock
Intake Valve Diameter: 2.165" x 4.89"
Exhaust Valve Diameter: 1.59" x 4.89"
Valve Stem Diameter: 8mm
Valve Spring Pocket I.D.: 1.30"
Valve Guide Material: Manganese Bronze
Valve Guide O.D.: .502" (.560" at base)
Rocker Design: LS3 Rails required
Valve Angle: 15°
Deck Thickness: .625"
