Brian Crower CNC New Head Cylinder Head TPR Industry Polaris XP 1000 XP Turbo w/ Used Core Exchange (TPR091)

Brian Crower CNC New Head Cylinder Head TPR Industry Polaris XP 1000 XP Turbo w/ Used Core Exchange

Brand: Brian Crower
Part Number: TPR091

Description:

Brian Crower CNC New 3023319 Head Cylinder Head TPR Industry Polaris XP 1000 XP Turbo w/ Used Core Exchange (upon inspection) (Without Cams)

There’s big horsepower gains to be made from proper cylinder porting and TPR Industry's CNC ported cylinder head for the Polaris XP1000 and XP Turbo applications deliver the best flow characteristics in terms of strength, direction, and condition of the air/fuel charge as it enters the cylinder through the intake valve. If you have exceptional charge motion, the cylinder will continue to fill even after the piston hits bottom dead center (BDC) and the air/fuel charge will evenly disperse in the chamber. All of this working cohesively makes horsepower.

TPR has spent weeks hand porting numerous heads, then hours on the flow bench analyzing all of the hand ported chamber and port designs and integrating only the best features into one CNC program to deliver the absolute best cylinder head money can buy. We have done extensive R&D, thousands of miles of testing, both on the dyno and out in the field, in order to determine the absolute best performing combination of parts that also delivers unprecedented durability. We don’t compromise on quality and these heads are basically works of art compared to other industry offerings, therefore these heads, with TPR’s full 5-axis CNC ported intake, exhaust and combustion chambers, are not sold as bare units.

All TPR heads come fully loaded with only the best Brian Crower valve train components, including valve springs wound by PAC in single beehive or dual designs, both featuring extra processing procedures to enhance performance. Your choice of titanium (beehive only) or tool steel retainers, +1mm stainless steel intake valves and Nimonic (Inconel) on the exhaust side in a massive +3.8mm oversize head diameter to greatly enhance the flow characteristics of a factory head that was intentionally dumbed down by Polaris for emissions purposes. The TPR/BC head package only features 4140 alloy, DLC coated buckets/cam followers...we’ve seen enough worn out/dished buckets to make this a mandatory feature on all TPR/BC head offerings. Also included - ARP cam cap/cam gear bolt kit, as well as BC custom bronze guides and valve seals.

EXHAUST

VALVE LIFT/CFM

TPR/BC cylinder head offered in the following:

#TPR091 - Brand new Polaris #3023319 TPR/BC CNC ported cylinder head w/complete BC valve train, ARP cam cap/cam gear bolt kit, new head (#3023319) with used cylinder core exchange (upon inspection). Price based on customer supplying used head for exchange (upon inspection). This fully assembled head includes the following:

BC8880-DLC cam followers, BC0900 (beehive) or BC0900D (dual) spring/retainer kit (choice titanium or tool steel retainers), BC3802 +1mm stainless steel intake valves, BC3807 +3.8mm Inconel exhaust valves, BC keepers, BC bronze guides, BC beryllium exhaust seats, BC3990 valve stem seals, BC3890 valve lash shim kit (50pcs), ARP cam cap/cam gear bolt kit (BC9009), TPR CNC port and chamber design, 5 angle valve job, cylinder head surfacing, hot tank cleaning, install oversize exhaust seats, install bronze int/exh guides, hone valve guides.

Available options not included with this item: BC or stock camshafts installed and fully lashed. Specify when ordering.

Fitment

• Make: Polaris
• Model: RZR XP 1000 2014+, RZR XP Turbo 2016+, RZR XP Turbo S 2018+, RZR Pro XP 2020+
• Engine: ProStar 1000, ProStar Turbo 925

Specifications

• Note: New Head 3023319 (Pro XP) w/ Used Core Exchange (upon inspection). Without Camshafts Installed. Please contact us if you want to add Stock cams, BC regrinds or BC new cams (XP1000 only).
• Open Pressure: 197lbs @ 21.59mm (Beehive) or 233lbs @ 20.70mm (Dual)
• Coil Bind: 19.30mm (Beehive) or 19.56mm (Dual)
• Valve Spring Type: Beehive, Dual
• Stem Diameter: 5.48mm
• Seat Pressure: 83lbs @ 32.13mm (Beehive) or 90lbs @ 32.13mm (Dual)
• Valve Length: 95.88mm|96.65mm
• Valve Head Size: 0.040" / 1mm, 0.150" / 3.8mm
• Valve Head Diameter: 30.2mm, 33mm
• Valve Type: Intake & Exhaust
• Valve Stem Diameter: 5.48mm
• Valve Material: Inconel, Stainless Steel
• Valve Guide Size: Standard
• Valve Guide Material: Manganese Bronze
• Valve Finish: Polished
• Valve Face: Dish
• Retainer Material: Steel, Titanium

Please note: This is a special order item by Stealth Ride. Usual wait times are 5–15 working days. If your order is urgent or you're concerned about potential delays, please contact us before purchasing.
