Aeroflow Top Plate with 4 Bolt Throttle Body Flange For Modular Intake Manifolds, Carbon Finish Suit 102mm/105mm Throttle Body, No Burst Panel
The Aeroflow Performance modular intake manifolds allowthe end user to customize their intake manifold depending on each individual application. This 4 layer carbon top plate performs well and works great as a centre piece of any engine bay when paired with our modular bases (sold separately) to make a complete intake manifold for the very popular GM LS engine family.
Aeroflow offer either a hi rise manifold where bonnet modifications will be required. The long runner design allows for high rpm horsepower with big cube engines for a serious drag racer. A low-rise design manifold which allows it to fit under a stock bonnetin most street car applications. Short intake runners with tapered top are designed to increase air velocity and more evenly distribute airflow to all 8 cylinders improving performance and throttle response.
The modular design is made up of the bottom base which bolts to the cylinder heads and the top plate which bolts to the base with an O-ring to seal both components. This top plate features a short throttle body snout to accept a 102mm 4 bolt GM LS throttle body.
These top plates can be paired with our modular bases which are sold separately. Available in a complete 4 layer carbon fibre material for weight saving and stunning looks. It features no burst panel and safe to use up to 30psi of boost.
