LS Next SHP Cast Iron Engine Block 4-Bolt Steel Caps4.125" Bore, 9.240" Deck, Short SkirtBlockBrand: DARTPart Number: DA31837211Description: Dart’s LS Next block is the first significant change in the architecture of the LS engine platform. By eliminating the “Y-block” design and utilizing conventional style main caps and oil pans, Dart has addressed the problems resulting from the LS engine’s separated crankcasebays. Windage is greatly reduced, resulting in increased power along with a much stronger main web area.
Features:
- Dart’s LS Next block is cast in the USA with premium cast iron alloy
- Conventional style 4-bolt steel main caps with 7/16” bolts are used
- Full main webbingfor maximum bottom end strength
- Cylinder barrels are extended by .375” at the bottom, providing greater piston support for all combinations
- 9.240” deck height, with options of 9.450" are available which allows for a possible effective barrel length of 9.825” deck block
- Extra thick Siamese cylinder bores allow for large displacement capacity, and a max bore size of at least 4.200”
- A5/8” thick full deck design with a 9.240” deck height
- Six head bolts per cylinder provide secure clamping for power adder applications
- Head bolts are upgraded to 7/16” for increased strength
- Blind head bolt holes don’t go through into the water jacket
- Provision for oil restrictors in the lifter valley
- Revised low restriction priority main oiling system
- Pro-Stock / Pro-Mod big block style stepped main oil galley
- An external oilfilter must be used with stockor aftermarket oil pumps
- Dual starter mounts
- The water jacket on the #1 cylinder has been expanded for additional cooling capacity
- LSX style lifter bosses and dog bone provision are provided
- Moroso oil pan suit DART LS NEXT BLOCK MO20144
- Oil pickup suit DART LS NEXT BLOCK MO24144
