750 CFM Marine Series CarburettorElectric choke, square flange, Mild Marine PerformanceBrand: EDELBROCKPart Number: ED1410Description:
- Designed and calibrated for optimum marine performance in small-block and big-block V8 engines with Performer RPM, RPM Air-Gap and Torker II manifolds and with Performer manifolds on large cubic-inch engines.
- Cast surfaces are iridited with Teflon-coated shafts.
- These carbs have no vacuum ports and are not for automotive use.
- Comes with the following jets, rods and springs: Metering Jets - Primary .113", Secondary .107"; Metering Rods - .071" x .047"; Step-Up Spring - orange (5" Hg).
For use in marine applications, these Edelbrock carbs comply with U.S. Coast Guard safety standards. Cast surfaces are iridited with Teflon-coated shafts and pump arm for maximum protection. Other features include modified bowl venting, specially designed throttle shafts, accelerator pump seal, 3/8" inverted flare fuel inlet fitting, tube in airhorn for fuel pump vent, 5-1/8" flame arrestor flange, universal throttle lever and revised secondaries for improved transient performance.
