Performer RPM 351C Cylinder Heads - Single - CompleteFord 302-351C 2V, 60cc combustion chambers, 190cc intake portBrand: EDELBROCKPart Number: ED61629Description: Performer RPM heads are perfect for street performance, daily drivers, street rods and muscle cars where seat-of-the-pants performance is needed. These heads give great torque and horsepower up to 6500 rpm.
- Designed for 302-351C, 351M & 400M Ford engines.
- Very streetable 190cc intake runners.
- 2.05" intake and 1.60" exhaust valves.
- "Compact charge" combustion chamber design.
- Intake and exhaust ports based on 2V design.
- Optimised spark plug location provides improved header clearance.
- Match with Edelbrock RPM Air-Gap manifolds for optimum performance.
Combustion chamber volume: 60cc
Intake runner volume: 190cc
Exhaust runner volume: 90cc
Intake valve diameter: 2.05"
Exhaust valve diameter: 1.60"
Valve stem diameter: 11/32"
Valve guides: Manganese bronze
Deck thickness: 5/8"
Valve spring diameter: 1.55"
Valve spring maximum lift: .580"
Rocker stud: 7/16"
Guide plate: Hardened Steel
Pushrod diameter: 5/16"
Exhaust port location: Stock
Spark plug fitment: 14mm x 3/4" reach, gasket seat
Made In: USA
