Turbosmart GenV CompGate40CG 'Compressed Gas' 5psi External Wastegate - Black
External WG
Brand: Turbosmart
Part Number: TS-0552-1202
Description:
GenV CompGate40 CG for Compressed Gas and C02 External Wastegate is designed for control strategies that require a large tuning window and large pressure differentials from the top to lower actuator housings, whereas traditional actuators on poppet style gas can achieve around 2-3x base spring pressure, the CG / C02 Version is capable of extreme multiples of the base pressure through the use of additional reference signal, high-pressure gas and C02.
The GenV CG and C02 variants are equipped with an inverted diaphragm, which is capable of high-pressure and high-pressure differentials (top to bottom), facilitating large tuning windows and the large boost-bandwidth associated with Drag Racing, Rally and Rally RX systems.
The GenV provides extensive user configurability, world-leading extended thermal performance, fatigue resistance and best-in-class flow performance for optimum control and longevity. The GenV External Wastegate Range is CFD optimized and real-world validated in-house for maximum flow and thermal management. The GenV range has more features, options and performance than any other gate. and includes a variable actuator cap and base for easy, 360-degree optional routing of reference hoses, strap-type V-band clamps, optional liquid-cooling provision, 1/8″ NPT reference ports and are provided with the full range of available springs.
Options
Hall Effect Position Sensor Cap Upgrade
Features
Class Leading, Thermal Performance
Class Leading, CFD and Bench-Validated Flow Performance
Class Leading Fatigue Resistance
Nitronic 60 Valve Guide and High Temp 347 SS Body
17/7 PH Stainless Steel Springs
Liquid Actuator Cooling Option
Strap Type V-band clamps
User Adjustable Actuator Position
Modular Design for Actuator Interchangeability
Technical Drawings:
Click HereWhats in the Box:
SUPPLIED WITHGenV Wastegate Unit
All Springs Included in Box
Spring Prefitted as per description
Valve Seat
Inlet and Outlet Weld Flanges & Clamps
Collar Tool
4 x 1/8 NPT Plugs
2 x 1/8 NPT Hose Tail Fittings
Spares and Accessories:
https://stealthride.co.nz/products/gen-v-wg38-40-cg-diaphragm-replacement-kit/https://stealthride.co.nz/products/gen-v-wg38-40-actuator-collar/https://stealthride.co.nz/products/gen-v-slave-collar-heatshield/https://stealthride.co.nz/products/gen-v-v-band-replacement-nuts-2-pack/https://stealthride.co.nz/products/gen-v-wg40-valve-seat/https://stealthride.co.nz/products/wg40-inlet-weld-flange/https://stealthride.co.nz/products/wg40-outlet-weld-flange/https://stealthride.co.nz/products/gen-v-wg40-inlet-wg45-outlet-v-band/https://stealthride.co.nz/products/gen-v-wg40-outlet-v-band/https://stealthride.co.nz/products/gen-v-wg38-40-3psi-black-inner-spring/https://stealthride.co.nz/products/gen-v-wg38-40-5psi-grey-inner-spring/https://stealthride.co.nz/products/gen-v-wg38-40-7psi-pink-middle-spring/https://stealthride.co.nz/products/gen-v-wg38-40-complete-sensor-cap-black/https://stealthride.co.nz/products/1-8th-npt-6mm-hose-tail-fittings-blanks/https://stealthride.co.nz/products/1-8-npt-to-3an-male-ss/https://stealthride.co.nz/products/1-16npt-male-1-8npt-female-fit/https://stealthride.co.nz/products/1-8-npt-90o-pushloc-fitting-ss-1-4/https://stealthride.co.nz/products/1-8-npt-tee-pushloc-fitting-ss-1-4/https://stealthride.co.nz/products/1-8-npt-str-pushloc-fitting-ss-1-4/https://stealthride.co.nz/products/1-4-nylon-tubing-black-3m/https://stealthride.co.nz/products/gen-v-cg-diaphragm-replacement-tool/https://stealthride.co.nz/products/gen-v-spring-change-assistance-kit/Specifications
-
Product Family: CompGate40
-
Colour: Black
-
Fitment Type: Universal
