GKTech 86, GR86, BRZ Anti Dive Relocator Bracket (GT86-ANTD)
Suits Toyota / Subaru 86 ZN6, BRZ ZC6, GR86 ZN8, BRZ ZD8
Brand: GKTech
Part Number: GT86-ANTD
Description:
GKTech 86, GR86, BRZ Anti Dive Relocator Bracket, part number GT86-ANTD. Suits Toyota 86 ZN6, Subaru BRZ ZC6, Toyota GR86 ZN8, Subaru BRZ ZD8. Designed and engineered by GKTech in Australia, supplied in New Zealand by Stealth Ride.
This Gktech 86 / GR86 / BRZ Anti dive relocator bracket is designed to improve your vehicle’s suspension handling by relocating the pickup point on the chassis by up to 20mm downwards. This adjustment significantly increases anti-dive and stability during braking.
- Relocated the pickup point on the chassis up to 20mm down to increase anti-dive.
- Anti dive increased from 1.3% at OEM to 26.6%
- Has multiple adjustment shims for tuning optimal anti-dive.
- Constructed from 6061-T6 Billet Aluminium bracket and 4130 Chrome-Moly spacers.
- Works with OEM arm, OEM bush, GK Spherical Bearing (GT86-CBSH), or GK FLCA's.
Want to deep dive further into the Anti Dive topic? Checkout GKTech's blog post by clicking HERE
Suits
- Toyota 86 ZN6 (2012–2021), FA20
- Subaru BRZ ZC6 (2012–2021), FA20
- Toyota GR86 ZN8 (2021–on), FA24
- Subaru BRZ ZD8 (2021–on), FA24
