GKTech S13 180SX, S14 & S15 200SX Wheel Studs (SSTUDSBUNDLE)
Suits Nissan S13, S14, S15, A31, C33, C34 & more
Brand: GKTech
Part Number: SSTUDSBUNDLE
Description:
GKTech S13 180SX, S14 & S15 200SX Wheel Studs, kit part number SSTUDSBUNDLE. Suits Nissan S13, S14, S15, A31, C33, C34 & more. Designed and engineered by GKTech in Australia, supplied in New Zealand by Stealth Ride.
Over time, wheel studs can become worn, damaged or corroded and may need to be replaced.
The Gktech OEM length wheel studs are ideal for replacing your factory studs and yes, these are a direct OEM replacement.
If you plan on running slip-on wheel spacers then stud length becomes extremely important as the spacer sits between the wheel and hub, this reduces the amount of available thread on the factory studs.
This can result in insufficient thread engagement between the wheel nut and stud which can be super dangerous.
The GKTech extended wheel studs are 20 mm longer than the OEM studs, providing the additional length required for slip-on spacers while maintaining proper wheel nut engagement.
Both the OEM length and the extended studs are available in either 12.8mm, 13.0mm or 14.3mm knurl size.
- Available in 12.8mm, 13mm and 14.3mm knurls
- OEM Length option
- Extended +20mm option
- M12x1.25 thread
- Grade 10.9 studs
Sold as a pack of 10 although GKTech do offer individual studs HERE
Please refer to the fitment guide to determine which studs you need.
NOTE: Their size chart is based on the original OEM hub part numbers and is accurate 99% of the time. However, variations can occur due to factory changes, replacement hubs, or aftermarket hubs being fitted to your vehicle.
To ensure the correct fit, they recommend checking the O.D. of your existing wheel studs and comparing it with their size chart before purchasing.
FITMENT CHART
| VEHICLE |
CHASSIS |
APPLICATION |
FRONT |
REAR |
| S13/Silvia/180sx |
S13 |
All Models |
13.0mm |
12.8mm |
| 200sx |
S14 |
All Models |
14.3mm |
13.0mm |
|
S15 |
All Models |
14.3mm |
13.0mm |
| Cefiro |
A31 |
2WD Models |
13.0mm |
13.0mm |
| Laurel |
C33 |
All Models |
13.0mm |
13.0mm |
|
C34 |
All Models |
14.3mm |
13.0mm |
|
C35 |
All Models |
14.3mm |
13.0mm |
| Cedric/Gloria |
Y31 |
All Models |
13.0mm |
13.0mm |
|
Y32 |
All Models |
13.0mm |
13.0mm |
|
FY32 |
4WD Models |
14.3mm |
14.3mm |
|
FY33 |
All Models |
13.0mm |
14.3mm |
|
FY50 |
Until Aug. 03' |
14.3mm |
13.0mm |
|
FY50 |
From Aug. 03' |
14.3mm |
14.3mm |
Options
-
Fronts?: None, 13.0mm knurl OEM length (1300-OEMX), 13.0mm knurl +20mm extended (1300-50MM), 14.3mm knurl OEM length (1430-OEMX), 14.3mm knurl +20mm extended (1430-50MM)
-
Rears?: None, 12.8mm knurl OEM length (1280-OEMX), 12.8mm knurl +20mm extended (1280-50MM), 13.0mm knurl OEM length (1300-OEMX), 13.0mm knurl +20mm extended (1300-50MM), 14.3mm knurl OEM length (1430-OEMX), 14.3mm knurl +20mm extended (1430-50MM)
Suits
- Nissan 180SX S13 (1989–1991), CA18DET
- Nissan Silvia S13 (1988–1991), CA18DET
- Nissan 180SX S13 (1991–1998), SR20DET
- Nissan Silvia S13 (1991–1993), SR20DET
- Nissan Silvia / 200SX S14 (1993–1998), SR20DET
- Nissan Silvia / 200SX S15 (1999–2002), SR20DET
- Nissan Cefiro A31 (1988–1994), RB20DET
- Nissan Laurel C33 (1989–1993), RB20DET
- Nissan Laurel C34 (1993–1997), RB25DET
- Nissan Laurel C35 (1997–2002), RB25DET
