King Bearings Rod Bearings STD OPEL 1.6L, 1.8L, C20XE C20LET 2.0L, 2.2L
Brand: King Bearings
Manufacturer's Part Number: CR4017XP
Stealth Ride Part Number: CR4017XP
UPC: 611500556364
Description:
The XP Tri-Metal Racing Series Successful race engine builders are constantly pushing the limits of load capacity to new levels. Race bearings today inevitably need to match these demands with more competitive bearings. At King Racing we met the challenge with the XP high performance bearings series.
The XP series is a line of bearings with advanced metallurgical and geometric technologies that meet extreme performance loads. It was developed for all performance applications that use forged steel aftermarket crankshafts and produce high loads for extended periods.
King Racing’s XP series features pMax Black™, a unique tri-metal structure that is 24% harder than any other conventional tri-metal race bearing. pMax Black™ together with the XP geometric features are the ideal combination for performance racing. For more on King Racing technologies visit TechLab
Description: OPEL 1.6L, 1.8L, 2.0L, 2.2L
Bearing Types:
CR - Con Rod bearing set
Material construction:
XP - Tri-metal copper lead
Bearing size inches
Dimension / Under Size e.g. "STD" for Standard, X equals .001" extra Clearance
| Bearing Size Inches | STDX | STD | .001" | 010X | .010" | .011" | 020X | .020" | .021" | .030" |
| Bearing Size metric | STDX | STD | .025 | | .25 | | | 0.5 | | 0.75 |
| Crankshaft undersize | 0 | 0 | 0 | -.010" | -.010" | -.010" | -.020" | -.020" | -.020" | -.030" |
| Additional Shell Thickness (on nominal) | -.0005" | 0 | +.0005" | +.0045" | +.005" | +.0055" | +.0095" | +.010" | +.0105" | +.015" |
More Information | Barcode | 611500556364 |
| UPC Code | 611500556364 |
| Shipping Weight (Dimensional) | 0.330000 |
| Clearance Sale | No |
| Availability | Call |
| Part Type | Connecting Rod Bearings |
| Make | Opel, Vauxhall |
| Model | Astra F 91-98, Calibra 90-97, Astra GTE 88-91 |
| Engine | C20LET, C20XE |
| Brand | King Bearings |
| Competitor Interchange Part Number | 4B2322H CB-1408AL 4-1490CP |
| Bearing Class | Race |
| Bearing oversize | STD (Standard) |
| Carb Legal | Unspecified |
| Shipping Label | |
Please note: This is a special order item by Stealth Ride. Usual wait times are 5–15 working days. If your order is urgent or you're concerned about potential delays, please contact us before purchasing.
