Supertech Forged Pistons Set Audi VW 2.0T 2.0L FSI EA113 82.5mm STD -12.5 cc 9.0:1
Brand: Supertech
Part Number: P4-VW20T825-N13-H13/GNH8250
Description:
Supertech Forged Pistons Set Audi VW 2.0T 2.0L FSI EA113 82.5mm STD -12.5 cc 9.0:1 * Requires Aftermarket EA113 Rods with non-tapered 20mm wrist pin *
Pistons are manufactured in Argentina with technology transferred from European manufacturers.
Our pistons are manufactured from extruded high silicon, enhanced 4032 alloy (with additional Cu, Ni & Mg) that has low thermal expansion, excellent wear resistance and higher thermal conductivity. Our pistons with this alloy have withstood up to 42psi of turbo boost, with alcohol, without any problems.
A 2 or 3 forging steps process yields a fine structural grain oriented in fibers in the same direction of the stresses.
Several heat treatments provide the piston with a high tensile strength and evenly distributed hardness. The pistons are submitted to several machining steps in specially designed machines and in conventional CNC. machines with special diamond tools for dimensional precision, perpendicularity and flatness of the ring grooves. Contact reduction grooves are standard. Honed & reamed pin bores for precise fit.
Wrist pins are constructed of H13 Tool Steel.
Finally our "phosphate dry lubricant" coating is applied to protect the rings against "micro welding" and enhance lubrication on the skirt/cylinder area.
Piston Rings are manufactured in Japan with the latest technology for high performance applications.
Quality Control: Performed after every step of the manufacturing process in climate controlled environments to ensure reliability of dimensions.
Fitment
-
Make: Audi, Volkswagen
-
Vehicle Model: GTI / Jetta / A3 / A4 / TT
-
Model: TT 08-09 MK2 8J, A3 FWD 06-08 MK2 8P, GTI 06-08 MK5, Jetta 06-08 MK5, Passat 06-08 B6, A4 FWD 05-08 B7 8E/8H, A4 Quattro 05-08 B7 8E/8H
-
Engine: 2.0T FSI EA113
Specifications
-
Note: Requires Aftermarket Connecting Rods with non-tapered 20mm Wrist Pin.
-
Item Weight: 302 g
-
Rod Length: 5.669" / 144mm
-
Rod Length Oversize: Standard Length
-
Bore Diameter: 82.5mm
-
Bore Oversize: Standard Bore
-
Stroke: 92.8mm (Standard Stroke)
-
Compression Ratio: 9.0:1
-
Pin Size: 0.787" / 20mm
-
Included Ring Set: R82-GNH8200
-
Head cc: 45 cc
-
Dome cc: -12.5 cc
-
Compression Height: 1.165" / 29.6mm
-
Piston Coating: Crown Coating, Skirt Coating
-
Skirt Type: Full Round
-
Piston Material: 4032
-
Pin Material: H13 Tool Steel
Please note: This is a special order item by Stealth Ride. Usual wait times are 5–20 working days. If your order is urgent or you're concerned about potential delays, please contact us before purchasing.
