GKTech Replacement bearing (PCML12TS)
Suits a wide range of Nissan models
Brand: GKTech
Part Number: PCML12TS
Description:
GKTech Replacement bearing, part number PCML12TS. Suits Nissan 180SX S13, Nissan Silvia S13, Nissan Silvia S14, Nissan Silvia S15, Nissan Skyline GT-R R32, Nissan Skyline GTS-T R32, Nissan Skyline GT-R R33, Nissan Skyline GTS-T R33, Nissan Skyline GT-T R34, Nissan 350Z Z33, Nissan 370Z Z34, Nissan Skyline V35, Nissan Skyline V36, Nissan 300ZX Z32. Designed and engineered by GKTech in Australia, supplied in New Zealand by Stealth Ride.
Replacement PCML12TS bearing Used in the following GKTECH products:
R32 front upper camber arms (SKU= R32X-FUCA)
Z32 front upper camber arms (SKU = Z32X-FUCA)
Z34 370z/ V36 4130 Chromoly Super Lock Lower Control Arms (SKU = 370Z-FLCA)
PCML12TS
| IMPERIAL |
METRIC |
| ROD END BALL BORE SIZE |
ROD END BALL BORE SIZE |
| 0.7500 in |
19.0500 mm |
| ROD END BALL WIDTH |
ROD END BALL WIDTH |
| 0.8750 in |
22.2250 mm |
| THREAD LENGTH |
THREAD LENGTH |
| 1.7500 in |
44.4500 mm |
| THREAD SIZE |
THREAD SIZE |
| 3/4 - 16 UNF LH |
3/4 - 16 UNF LH |
| ROD END HEAD DIAMETER |
ROD END HEAD DIAMETER |
| 1.7500 in |
44.4500 mm |
| ROD END MISALIGNMENT ANGLE |
ROD END MISALIGNMENT ANGLE |
| 24 degrees |
24 degrees |
| ROD END STATIC LOAD CAPACITY (lbs) |
ROD END STATIC LOAD CAPACITY (kg) |
| 21,400 lbs |
9,707 kg |
| ROD END MATERIAL |
ROD END MATERIAL |
| Chromoly |
Chromoly |
| LUBRICATION |
LUBRICATION |
| PTFE lined |
PTFE lined |
Suits
- Nissan 180SX S13 (1989–1991), CA18DET
- Nissan Silvia S13 (1988–1991), CA18DET
- Nissan 180SX S13 (1991–1998), SR20DET
- Nissan Silvia S13 (1991–1993), SR20DET
- Nissan Silvia / 200SX S14 (1993–1998), SR20DET
- Nissan Silvia / 200SX S15 (1999–2002), SR20DET
- Nissan Skyline GT-R R32 (1989–1994), RB26DETT
- Nissan Skyline GTS-T R32 (1989–1993), RB20DET
- Nissan Skyline GT-R R33 (1995–1998), RB26DETT
- Nissan Skyline GTS-T R33 (1993–1998), RB25DET
- Nissan Skyline GT-T R34 (1998–2002), RB25DET
- Nissan 350Z Z33 (2002–2009), VQ35DE
- Nissan 370Z Z34 (2009–2020), VQ37VHR
- Nissan Skyline V35 (2001–2007), VQ35DE
- Nissan Skyline V36 (2006–2014), VQ37VHR
- Nissan 300ZX Z32 (1989–2000), VG30DETT
